- Place of Origin: Shandong, China (Mainland)
- Brand Name: WZA
- Model Number: 23226E
Quick Details
Structure: Spherical, Spherical
Type: Roller
Brand Name: WZA
Bore Size: 130 - 130.001 mm
Outside Diameter: 230 - 230.001 mm
Model Number: 23226
Precision Rating: P6 P5
Seals Type: Open
Number of Row: Double Row
Place of Origin: Shandong, China (Mainland)
Material:Gcr15/Gcr15SiMn/G20Gr2Ni4A/Stainless Steel
Cage: Brass cage, steel cage, nylon cage
Bore size (d): 20-1800mm
Outer size (D): 52-2180mm
OEM service: Available
Introduction: High Quality Material,German grinding process,
Application: Automotive, electrical, construction machinery, professional machinery
Certification: ISO9001
Packaging & Delivery
| Packaging Details: | Brand original package, others according to the requirements |
|---|
A.Products
1. Bore size (d)- 20-1800mm
2. Outer size (D)- 52-2180mm
3. Application: automotive. Electrical, construction machinery and various kinds of professional machinery
4. Main market: America, European, Africa, Middle East and Southeast Asia
5. Introduction: Imported equipment and European technology
B. Specifications
1. Brand Name: WZA & OEM
2. High precision, long life, low noise, high-end technology, low vibration and conform to the export standard
3.Package: Box packing, industrial standrad packing, individual box packing or as customers' requirement
C.Description
| Bearings NO. | d | D | B | C | C0 | Weight |
| mm | mm | mm | kN | kN | kg |
| 22226 CCK/W33 | 130 | 230 | 64 | 735 | 930 | 10.7 |
| 22226 CAK/W33 | 130 | 230 | 64 | 735 | 930 | 10.7 |
| 22226 EK | 130 | 230 | 64 | 735 | 930 | 10.7 |
| 23226 MB/W33 | 130 | 230 | 80 | 780 | 1060 | 14.5 |
| 23226 CC/W33 | 130 | 230 | 80 | 780 | 1060 | 14.5 |
| 23226 CA/W33 | 130 | 230 | 80 | 780 | 1060 | 14.5 |
| 23226 MBK/W33 | 130 | 230 | 80 | 780 | 1060 | 14 |
| 23226 CCK/W33 | 130 | 230 | 80 | 780 | 1060 | 14 |
| 23226 CAK/W33 | 130 | 230 | 80 | 780 | 1060 | 14 |
| 22326 MB/W33 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 CC/W33 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 CA/W33 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 MB/W33VA405 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 CC/W33VA405 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 CA/W33VA405 | 130 | 280 | 93 | 1120 | 1320 | 29 |
| 22326 MBK/W33 | 130 | 280 | 93 | 1120 | 1320 | 28.5 |
| 22326 CCK/W33 | 130 | 280 | 93 | 1120 | 1320 | 28.5 |
| 22326 CAK/W33 | 130 | 280 | 93 | 1120 | 1320 | 28.5 |
